Ra-01SH SX1262 868MHz LoRa Module

Features / Specs Manufacturer: Ai Thinker Part Number: Ra-01SH Antenna Connection: Solderable Pad RF Transceiver: Semtech SX1262 Operating Voltage: 2.5 ~ 3.7VDC Operating Current (Max): ~140mA Receive Mode Current (Min): ~4.6mA Standby Mode Current: ~1.6mA Comms Interface: SPI Frequency Range: 803 – 930MHz Receive Sensitivity: As low as -140dBm Max Transmit Power: 22dBm Bit Rate: Programmable up to 300kbps Modulation Types: FSK, GFSK, MSK, GMSK, LoRa and OOK Notable Features: Excellent blocking immunity and additional shielding Operating Temperature: -40°C to 85°C Certifications: REACH / RoHs Dimensions: (17mm x 16mm x 3.2mm) ±0.2mm Pitch: 2.0mm ±0.1mm Resources Semtech SX1262 Product Page Ai Thinker Ra-01SH Datasheet v1.1
