ESP32-S3 TN LCD Board – 7 Inch Capacitive Touch

Features / Specs Manufacturer: Shenzhen Jingcai Intelligent Co., Ltd (GUITION) Model Number: ESP32-8048S070C Main Module: Espressif ESP32-S3-WROOM-1 (N16R8) (Xtensa® 32-bit LX7 Dual-Core Processor, Up to 240MHz) Flash Memory: QSPI 16MB ROM: 384kB SRAM: 512kB SRAM in RTC: 16kB PSRAM: 8MB Quad SPI In-Package Antenna Type: Onboard PCB Antenna Display Type: TFT LCD Panel Type: TN Display Size: 7.0 Inch Display Colour: 16-Bit RGB 65K Colour Display Resolution: 800 x 480 Pixels Effective Display Area: 153.84mm x 85.63mm Display Driver Chip: EK9716 Display Touch Functionality: Capacitive Touch USB to UART Interface IC: WCH CH340C USB Connector Type: Female USB Type-C Socket Supply Voltage: 5VDC (USB Type-C Connector; P1 Connector) Operating Voltage: 3.3VDC Operating Current (Average): ~500mA Connector Specs: P1 = GH 1.25mm 4P / P2 = GH 1.25mm 4P / P3 = GH 1.25mm 4P / P4 = GH 1.25mm 4P / P5 = SH 1.0mm 4P / P6 (Speak) = GH 1.25mm 2P Notable Features: TF Card Slot / Speaker Interface With Onboard Amplifier / BOOT and RESET Buttons / Up to 9 IO Connections Available Operating Temperature Range: ~(-20°C to 70°C) Dimensions: ~(181mm x 108mm x 11.8mm) Mounting Hole Diameter: ~3.2mm WiFi Protocols: 802.11 b/g/n (1T1R mode with data rate up to 150 Mbps) Frequency Band: 2.4GHz (Supports 20MHz and 40Mhz Bandwidth) Wireless Network Modes: Station / SoftAP / SoftAP Station Hardware Features: 45x Programmable GPIO’s / 4x SPI / 1x LCD Interface / 1x DVP Camera Interface / 3x UART / 2x I2C / 2x I2S / 1x RMT (TX; RX) / etc WiFi Security: Secure Boot / Flash Encryption / 4k-bit OTP, up to 1792 bits for users / Cryptographic Hardware Acceleration Bluetooth Protocols: Bluetooth LE – Bluetooth 5, Bluetooth Mesh Bluetooth Power: Up to 20dBm Bluetooth Speeds: 125kbps / 500kbps / 1MBps / 2MBps Bluetooth Advertising Features: Advertising Extensions / Multiple Advertising Sets Bluetooth Other Features: Internal co-existence mechanism allowing WiFi and Bluetooth to share a single antenna Resources Shenzhen Jingcai Intelligent ESP32-8048S070C Product Spec Shenzhen Jingcai Intelligent ESP32-8048S070C Resources Pack (123MB) Espressif ESP32-S3-WROOM-1 Datasheet v1.3 Sparkfun CH340 Driver Install Guide
